Arrow Dripper – Precise Irrigation, Moisture Directly to Crop Roots

Arrow drippers typically come in two forms: straight arrow dippers and bend arrow dippers. Their shape resembles an arrow, which can be inserted into the soil to precisely deliver water and nutrients directly to the plant roots. Arrow drippers significantly reduce water evaporation and waste, and are widely used for irrigating potted plants and small trees or seedlings in orchards.

Structure

Filter screen: Located at the entrance of the arrow dripper, it filters out impurities to prevent clogging.
Maze flow path: The long flow path reduces water pressure, ensuring uniform water output.
Arrow body: Water flow delivery.
Arrow-shaped outlet: The arrow-shaped outlet is convenient for insertion into the soil.

Arrow drippers can be used individually or in combination with distributors, drippers, and 1/4" drip tubes, commonly seen in double-arrow and four-arrow combinations.

Dripper: It is installed on the pipeline to deliver a stable and uniform water flow.
Distributor: It is installed at the dripper outlet, connected with 1/4" drip tubes to achieve dispersed water flow.
1/4" drip tube: It is connected with the distributor to disperse and deliver water flow.
Arrow dripper: It is connected with 1/4" drip tube, inserted into the soil to deliver water and nutrients to the crop roots.

An image of a four-arrow combination structure

Features

Precise irrigation and uniform water output: The arrow dripper is equipped with a fine labyrinth flow path and an additional precision filter at the handle, greatly enhancing its anti-clogging performance. Arrow drippers are usually used in combination with pressure-compensating drippers to maintain stable and uniform water output.
Modular combination: Arrow drippers can be combined with other drip irrigation equipment and can be freely assembled into single, double, four, or eight-arrow configurations for convenient use.
Water-saving and yield-increasing: By reducing waste and delivering water directly to where it is needed, it saves water resources while improving crop growth quality and yield.

Specifications

Table 1: Specifications of Arrow Dripper
Material: PE	Type: Single-dripper, 2-way, 4-way drippers
Capillary length: 50cm	Arrow length: 10 cm
Working pressure: 0.02–0.2 MPa	Flow rate: 1–3 L/H

Gallery

Four-arrow combination is irrigating four potted plants.

Four-arrow combination irrigating potted plants

Single arrow dripper inserted in ground for irrigation

Arrow dripper root irrigation

A single arrow is irrigating a potted plant.

Single arrow potted plant irrigation

Many arrow drippers are irrigating potted plants.

Arrow dripper potted plant irrigation
